Easyswap

Interchangeable Movable Point on Swing Nose Crossing

The Vossloh Easyswap system is an innovative solution designed to enhance the efficiency and sustainability of swing nose crossings. This exclusive development allows for the direct replacement of movable points on the track, significantly reducing lifecycle costs and minimizing disruption during maintenance operations. The Easyswap is the optimal choice for high-performance points and crossings, suitable for both high-speed and heavy haul lines.

Key Features

The Easyswap movable point can be replaced directly on the track, eliminating the need to remove the entire swing nose crossing.
Reduces maintenance costs, spare parts, and labor, leading to significant savings over the lifecycle of the crossing.
Compatible with all swing nose crossings, making it a versatile solution for various railway systems.
Designed for easy removal and installation, allowing for rapid adjustments and minimizing track downtime.
Enhances operational efficiency by reducing traffic interruptions during maintenance.

Maintenance Simplified

Replacing a conventional swing nose crossing typically involves multiple complex operations, including cutting rails, removing heavy components, and transporting them for repairs. The Easyswap system streamlines this process, reducing replacement time by up to 50%.

Conventional Replacement Process:

  1. Cut the 4 rails at the front and rear of the swing nose crossing.
  2. Remove the entire swing nose crossing (e.g., Tangent 1/46 L = 28.95 m - 8450 kg).
  3. Transport to the plant for repairs.
  4. Reassemble and transport back to the track.
  5. Install the new swing nose crossing and weld to the track.



Easyswap Replacement Process:

  1. Cut the 2 rails at the rear of the swing nose crossing.
  2. Remove the damaged movable point directly on the track.
  3. Install a new Easyswap movable point (e.g., Tangent 1/46 L = 24.52 m - 2850 kg) and weld to the track.

Technical Specifications



  • Weight of Movable Point: Approximately 2850 kg

  • Compatibility: Works with existing swing nose crossings

  • Operation: No special tools required for installation

  • Traffic Compatibility: Can be operated under traffic conditions, accommodating various speeds and temperature ranges.





The Future of Railway Maintenance

The Vossloh Easyswap system represents a significant leap forward in railway maintenance technology. By allowing for the quick and efficient replacement of movable points, it not only reduces costs but also enhances the overall reliability and availability of railway operations. As the demand for efficient and sustainable railway solutions continues to grow, the Easyswap stands out as a forward-thinking choice that meets the challenges of modern rail transport.

Contact us

For more information about the Easyswap system and how it can enhance your railway operations, please contact us.
